Replacement Nowata NFG Series NFG336 Particulate and Mist Removal for Dry & Wet Gas Filter

Name: Replacement Nowata NFG Series NFG336 Particulate and Mist Removal for Dry & Wet Gas Filter
Brand: MeiTong Filtration
SKU: 281

Replacement Nowata NFG Series NFG336 Particulate and Mist Removal for Dry & Wet Gas Filter - thumbnail

Replacement Nowata NFG Series NFG336 Particulate and Mist Removal for Dry & Wet Gas Filter

Meitong manufactures compatible replacement filter separator cartridges for the Nowata NFG Series, designed for natural gas vapor-phase filtration and liquid coalescing…

OD 3.5/4.5 inch

Height 12/ 24/36/72 inch

End caps Carbon Steel

Filter layer Fiberglass

Filtration rate 0.5,1 μm μm

Working temperature 275F (135C)

Skeleton Carbon Steel

Send Email WhatsApp

Product Details

Learn more about the specifications, features and benefits of our high-performance filter element.

Description

Meitong manufactures compatible replacement filter separator cartridges for the Nowata NFG Series, designed for natural gas vapor-phase filtration and liquid coalescing applications.

These forward-flow filter elements remove fine solid contaminants from natural gas while promoting the coalescence of entrained liquid droplets. Designed for outside-in flow, they help maintain effective filtration performance while minimizing excessive differential pressure buildup under suitable operating conditions.

The replacement cartridges are available in nominal filtration ratings of 0.5 and 1.0 micron, with multiple lengths and diameter configurations to accommodate different gas filtration systems.

Meitong provides compatible replacement elements for customers seeking an alternative supply source for natural gas filtration and separation equipment.

Why Choose Our Replacement Cartridges?

Direct Compatibility: Engineered to serve as reliable, high-performance replacements for Nowata NFG Series systems.

Enhanced Protection: Maximizes gaseous filtration purity, reducing compressor and turbine maintenance costs.

Extended Service Life: Thanks to the self-cleaning matrix and high structural integrity.

Typical Applications

Natural gas processing plants

Gas transmission and distribution systems

Gas filtration and separation stations

Industrial gas treatment systems

Vapor-phase filtration where solid contaminant removal and liquid coalescing are required

Specifications

Lenth	12/ 24/36/72inch
Outer Diameter	3.5/4.5inch
Outer Diameter	2/3 inch
Product Type	Particulate and Mist Removal Filter
Filter material	Fiberglass
Core/Outer Material	Carbon Steel
End caps	Carbon Steel
Gasket Material	Buna-N
Gasket Adhesive	Polyurethane
Outer Sock	Cotton
Flow Configuration	Outside-In
Temperature	275F (135C)
Maximum Differential Pressure	15 psid
Filtration Accuracy	0.5,1 μm

If you are interested in this filter, please contact us to get the price.

Features

Fine Particle Filtration: Fiberglass filter media captures fine solid contaminants in natural gas streams.

Liquid Coalescing: Promotes the coalescence of entrained liquid droplets for downstream separation.

Low Differential Pressure Buildup: Designed to provide effective filtration without excessive pressure drop under appropriate operating conditions.

Reinforced Construction: A spiral-locked carbon steel center core helps resist collapse under elevated differential pressure.

Secure End-Cap Sealing: Specialized sealant bonds the filter media, core, and end caps to reduce internal channeling and bypass.

Hydrocarbon Service: Buna-N gaskets and polyurethane adhesive are used in the original design; compatibility must be verified against the actual process fluid and operating conditions.

Multiple Configurations: Available in 3.5-inch and 4.5-inch outside diameters, with lengths ranging from 12 to 72 inches depending on the model.

Model Number

3.5"OD × 2"ID

Reference Model	Length	Nominal Rating
NFG12	12"	1 μm
NFG24	24"	1.0 μm
NFG36	36"	1.0 μm
NFG12UF	12"	0.5 μm
NFG24UF	24"	0.5 μm
NFG36UF	36"	0.5 μm

4.5"OD X 3"ID

Reference Model	Length	Nominal Rating
NFG312	12"	1.0 μm
NFG324	24"	1.0 μm
NFG336	36"	1.0 μm
NFG372	72"	1.0 μm
NFG312UF	12"	0.5 μm
NFG324UF	24"	0.5 μm
NFG336UF	36"	0.5 μm
NFG372UF	72"	0.5 μm
